Please Note, this product is not for consumer use in the European Union.

Intuitive LCD interface

Provides clear and accurate information in multiple languages with the ability to configure the

UPS locally with easy to use navigation keys.

Predictive replace battery date

Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.

Green mode

Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Energy meter

Provides actual kilowatt hours of usage for energy conscious users.

Sequenced shutdown and restart

Configure select outlet groups to shut down and turn on in a pre-determined order (for UPSs with switched outlet groups).

Pure sine wave output on battery

Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.

AC outlet types	C13 coupler,C19 coupler
AC outlets quantity	9 AC outlet(s)
Battery capacity	816 VAh
Battery recharge time	3 h
Battery technology	Sealed Lead Acid (VRLA)
Cable length	1.83 m
Cables included	RS-232,USB cable
Certification	CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH, PEP, EOLI
Colour of product	Black
Depth	544 mm
Dimensions (WxDxH)	435 x 197 x 544 mm
Display	LCD
Efficiency	98.1 %
Form factor	Tower
Height	435 mm
Hot-swap battery	Yes
Input connection type	IEC-320 C20
Input operation voltage (max)	302 V
Input operation voltage (min)	151 V
LED indicators	Status
Maximum current	16 A
Noise level	53 dB
Nominal input voltage	230 V
Nominal output voltage	230 V
Non-operating altitude	0 - 15000 m
Operating altitude	0 - 3000 m
Operating relative humidity (H-H)	0 - 95 %
Operating relative humidity range	5 - 95 %
Operating temperature (T-T)	0 - 40 °C
Operating temperature range (T-T)	0 - 40 °C
Output connections	8 x IEC 320 C13 1 x IEC 320 C19
Output power	2700 W
Output power capacity (VA)	3000 VA
Output voltage note	220/230/240
Package dimensions (WxDxH)	699 x 381 x 762 mm
Package height	699 mm
Package weight	63700 g
Package width	381 mm
Power supply input frequency	50/60 Hz
Quantity per pallet	9 pc(s)
Quick installation guide	Yes
Replacement battery cartridge	RBC55
RoHS compliance	Yes
Serial ports quantity	1
Source data-sheet	Icecat.biz
Storage relative humidity (H-H)	0 - 95 %
Storage relative humidity range	5 - 95 %
Storage temperature (T-T)	-15 - 45 °C
Storage temperature range (T-T)	-15 - 45 °C
Surge energy rating	365 J
Typical backup time at full load	5.1 min
Typical backup time at half load	17.2 min
USB port	Yes
Waveform	Sine
Weight	52500 g
Width	197 mm
